Stage 3:
Installing the FF 120
Ceiling Speakers
Stage 3 Involves installing the devices shown below.
•
Where it goes: Installs in ceiling tiles at a predetermined location for best acoustics.
Connects to the switcher.
•
What it does: Receives and outputs audio signal from the PVS 405D switcher.
FF 120 Flat Field Ceiling Speakers
Anchor Rings (2)
Cable Clamps (2)
Terminal Cover
T-rails (2)
FF 120 Speaker (2)
Seismic Tabs (3 per side)
SPK 18, 35 ft
Cabling for the Speakers
Speaker Installation:
•
Speaker cable (connects ceiling speakers to the
PVS 405D switcher).
PoleVault Digital Systems • Installation — Stage 3 (Speakers)
35
