Outline of Installation Steps for PoleVault Digital Systems
Stage 1 — Install the Screen and Projector
c Mark the screen location (page 18) .
c Install projector to verify location (page 18 ).
c Verify the image location (page 21) .
c Cut the ceiling tile (page 22) .
c Preliminary safety hardware installation (page 22) .
c Finish projector drop ceiling mount installation (page 23).
c Secure the projector drop ceiling mount to the ceiling (page 24) .
c Install the electrical box (if required) (page 25) .
c Install the screen (page 25) .
Stage 2 — Mount the PVT Wall Plates and the MLC 104 IP Plus.
c Install the mud rings (page 29) .
c Pull cables (at the input locations) (page 30) .
c Install the wall plates (page 31) .
c Install the MediaLink Controller (page 32) .
Stage 3 — Install the FF 120 Speakers.
c Cut the ceiling tile (page 36) .
c Install the speaker on the drop ceiling (page 36).
c Terminate the speaker cable for the PVS switcher (page 38).
Stage 4A — Install the PMK 560 and PVS 405D.
c Install the PMK 560 base plate (page 40) .
c Pull the cables (at the switcher location) (page 41).
c Finish installing the pole mount kit (page 43)
Stage 5 — Configure the PoleVault Switcher and the System.
c Configure the switcher — PCS Configuration program (page 61) .
c Configure the system — Global Configurator (page 62) .
c Test the system (page 63).
c Final installation (page 65) .
Optional Accessory Installation
c VoiceLift System (page 66) .
c Priority Page Sensor PPS 35 (page 67) .
c Priority Page Sensor Kit PPS 25 (page 69).
The pages listed above contain instructions for installing the PoleVault Digital System. Where possible, line
drawings and photos from an actual installation are used to clarify some of the steps discussed in the text. Most
images have a number corresponding to the step that is being described (for example,
Ñ ).
NOTE: Similar outline lists of steps for installing WallVault (WMK 160 or USFM 100) and PlenumVault
(PVM 220) Digital Systems can be found on pages 73 through 76.
PoleVault Digital Systems • Installation Overview 16
