Inventory — Wall Vault Systems (WMK 160)
Figure 6. WMK 160 for WVS 210D and WVS 410D WallVault Systems
42-211-03 WVS 210D
Part Number Description Quantity
26-621-50 MLC IR cable, 50 ft 1
26-626-50 MLC PW/RS-232 cable, 50 ft 1
26-627-35 Speaker cable, 35 ft 2
26-692-15 HDMI Plenum M-M cable, 15 ft 1
26-696-35 STP 201P cable, 35 ft 1
42-120-03 FF 120 speakers 1 pair
60-818-03 MLC 104 IP Plus 1
60-1235-01 PVS 405D 1
60-1335-03 PVT SW HDMI RGB D 1
70-1030-03 WMK 160 1
42-212-03 WVS 410D
Part Number Description Quantity
26-621-50 MLC IR cable, 50 ft 1
26-626-50 MLC PW/RS-232 cable, 50 ft 1
26-627-35 Speaker cable, 35 ft 2
26-692-15 HDMI Plenum M-M cable, 15 ft 1
26-696-35 STP 201P cable, 35 ft 2
42-120-03 FF 120 speakers 1 pair
60-818-03 MLC 104 IP Plus 1
60-1235-01 PVS 405D 1
60-1270-03 PVT SW HDMI D 1
60-1335-03 PVT SW HDMI RGB D 1
70-1030-03 WMK 160 1
(2) #14 x 1 3/4"
Self-tapping
Metal/Wood Screws
(4) 1/4-20 x 2"
Pan Head Bolts
(4) 1/4" KapToggle®
Assemblies
(4) Cover Screws
(1) PoleVault Switcher
Mounting Plate
(1) WMK 160 Cover
(1) WMK 160 Base Plate
(2) #14
Sel
Met
(4)
(4) 1/4"
Ass
(4) Cov
(1) Po
Mo
K 160 Base Plate e (1) WMK
