Alarms and events description and system troubleshooting guide 231
A
CPU Updates (firmware & options)
CPU Firmware Download
Started CPU firmware download process started
CPU Firmware Download
Complete New firmware has been downloaded to CPU
Upgrade Successful New option string successfully downloaded
to CPU
Upgrade Failure Internal Error 2 CPU detected an internal error during the
option upgrade process Contact GE Post Sales Service (see How to
contact us on page 2 ).
Upgrade Failure Internal Error 3 CPU detected an internal error during the
option upgrade process Contact GE Post Sales Service (see How to
contact us on page 2 ).
Upgrade Failure Internal Error 4 CPU detected an internal error during the
option upgrade process Contact GE Post Sales Service (see How to
contact us on page 2 ).
Upgrade Failure Option String
Corrupt Invalid or corrupted option string: incorrect
option string format Contact GE Post Sales Service (see How to
contact us on page 2 ).
Upgrade Failure Unable To
Decrypt Invalid or corrupted option string: decryption
failure or bad digital signature Contact GE Post Sales Service (see How to
contact us on page 2 ).
Upgrade Failure Due To Bad
CRC Invalid or corrupted option string: bad CRC Contact GE Post Sales Service (see How to
contact us on page 2 ).
Upgrade Failure Hardware
Mismatch Invalid or corrupted option string: MAC
address mismatch Contact GE Post Sales Service (see How to
contact us on page 2 ).
CPU Firmware Failure Previous
Version In Use CPU firmware upgrade operation failed; CPU
is using previous firmware version Contact GE Post Sales Service (see How to
contact us on page 2 ).
Attention New Messngr Options
Deficient More per-breaker options are enabled then
the number available per the option string.
This can occur when a new option string is
loaded that contains fewer per-breaker
options than the original option string. The CPU will allocate the options to the
lowest numbered breakers that have the
option specified. For metering options,
allocate the available meters to the desired
breakers. For relaying options, contact GE
Post Sales Service (see
How to contact us
on page 2 ).
Preventative Maintenance
Breaker In Service Anniversary Breaker anniversary date has been reached
Breaker Mechanical Life At XX
Percent See section on Preventative Maintenance
Breaker Load Life At XX Percent See section on Preventative Maintenance
Table A-2 Sequence of events description and troubleshooting guide
Event Description Notes and Troubleshooting tips
