FlexLogic™
150
11
ELEMENT:
Instantaneous
Overcurrent
IOC 1 OP
IOC 1 DPO
Instantaneous Overcurrent 1 activated
Instantaneous Overcurrent 1 deactivated
IOC 2…30
Same set of operands as shown for IOC 1
ELEMENT:
Long Time
Overcurrent
LONG TIME 1 PKP
LONG TIME 1 OP
LONG TIME 1 DPO
Long Time Overcurrent 1 in pickup
Long Time Overcurrent 1 tripped breaker
Long Time Overcurrent 1 not in pickup
LONG TIME 2…30
Same set of operands as shown for LONG
TIME 1
ELEMENT:
Multi-Source Ground
Fault
MSGF ZONE 1 TRIP DPO
MSGF ZONE 1 ALARM DPO
MSGF ZONE 1 TRIP PKP
MSGF ZONE 1 ALARM PKP
MSGF ZONE 1 TRIP OP
MSGF ZONE 1 ALARM OP
MSGF ZONE 1 TRIP BACKUP OP
Multi-Source GF Zone 1 trip function not in
pickup
Multi-Source GF Zone 1 alarm function not
in pickup
Multi-Source GF Zone 1 trip function in
pickup
Multi-Source GF Zone 1alarm function in
pickup
Multi-Source GF Zone 1 trip function has
tripped breakers
Multi-Source GF Zone 1 alarm activated
Multi-Source GF Zone 1 trip backup function
has tripped backup breakers
MSGF ZONE 2…4
Same set of operands as shown for MSGF
ZONE 1
ELEMENT:
Multi-Source Ground
Fault Summation Zone
MSGF SUMMATION ZONE 1 TRIP DPO
MSGF SUMMATION ZONE 1 ALARM DPO
MSGF SUMMATION ZONE 1 TRIP PKP
MSGF SUMMATION ZONE 1 ALARM PKP
MSGF SUMMATION ZONE 1 TRIP OP
MSGF SUMMATION ZONE 1 ALARM OP
MSGF SUMMATION ZONE 1 TRIP
RESTRAINED
MSGF SUMMATION ZONE 1 ALARM
RESTRAINED
Multi-Source GF Summation Zone 1 trip
function not in pickup
Multi-Source GF Summation Zone 1 alarm
function not in pickup
Multi-Source GF Summation Zone 1 trip
function in pickup
Multi-Source GF Summation Zone 1 alarm
function in pickup
Multi-Source GF Summation Zone 1 trip
function has tripped breakers
Multi-Source GF Summation Zone 1 alarm
activated
Multi-Source GF Summation Zone 1 trip
function restrained
Multi-Source GF Summation Zone 1 alarm
function restrained
MSGF SUMMATION ZONE 2
Same set of operands as show above for
MSGF SUMMATION ZONE 1
Table 11-2 Entellisys FlexLogic operands
OPERAND TYPE
OPERAND SYNTAX
OPERAND DESCRIPTION
