Alarms and events description and system troubleshooting guide
215
A
Voltage Above Undervoltage
Blocking Voltage
The voltage on at least one of the three
phases has exceeded the undervoltage
blocking voltage threshold.
Alarm Pickup Overvoltage
Alarm only overvoltage relay has entered
pickup
Alarm Overvoltage
Alarm only overvoltage relay has operated
Alarm Dropout Overvoltage
Alarm only overvoltage relay has dropped
out of pickup
Pickup Overvoltage
Overvoltage relay has entered pickup
Breaker Trip Overvoltage
Overvoltage relay has operated
Dropout Overvoltage
Overvoltage relay has dropped out of pickup
Alarm Pickup Phase Loss
Alarm only phase loss relay has entered
pickup
Alarm Phase Loss
Alarm only phase loss relay has operated
Alarm Dropout Phase Loss
Alarm only phase loss relay has dropped out
of pickup
Voltage Below Phase Loss Alarm
Blocking Voltage
The voltages on all three phases have
dropped below the alarm only phase loss
blocking voltage threshold.
Voltage Above Phase Loss Alarm
Blocking Voltage
The voltage on at least one of the three
phases has exceeded the alarm only phase
loss blocking voltage threshold.
Pickup Phase Loss
Phase loss relay has entered pickup
Breaker Trip Phase Loss
Phase loss relay has operated
Dropout Phase Loss
Phase loss relay has dropped out of pickup
Voltage Below Phase Loss
Blocking Voltage
The voltages on all three phases have
dropped below the phase loss blocking
voltage threshold.
Voltage Above Phase Loss
Blocking Voltage
The voltage on at least one of the three
phases has exceeded the phase loss blocking
voltage threshold.
Relays - High Current
Alarm Pickup High Current
High current relay has entered pickup
Alarm High Current
High current relay has operated
Alarm Dropout High Current
High current relay has dropped out of pickup
Table A-2 Sequence of events description and troubleshooting guide
Event
Description
Notes and Troubleshooting tips
