Alarms and events description and system troubleshooting guide
209
A
User With [USER ID] ID Logged
Into HMI
Indicates that the specified operator has
logged into the HMI application
User With [USER ID] ID Logged
Off HMI
Indicates that the specified operator has
logged out of the HMI application
Caution: Unable to Read HMI
Config File(elvs_config.bcf).
Defaults Loaded
The HMI was unable to load the local
configuration file from disk.
Contact GE Post Sales Service (see
).
HMI Config File Loaded OK
The HMI successfully loaded the local
configuration file from disk.
Caution: Error Saving HMI
Config File
The HMI was unable to successfully store the
local configuration file to disk.
Contact GE Post Sales Service (see
).
HMI Config File Saved OK
The HMI successfully loaded the local
configuration file from disk.
HMI is restarted for Periodic
maintenance
The HMI has restarted itself as part of its
periodic self-maintenance routine.
HMI/CPU Communications Related
Troubleshooting communications between
an HMI and a CPU:
• Check power to System Interface
Ethernet Switch.
• Check power and status of CPU.
• Check communications link status. LEDs
at the Ethernet ports on the HMI, switch,
and CPU should be green.
• Check communications with redundant
CPU by establishing it as the Primary
(default) unit.
• Verify that the IP address, subnet mask,
and gateway address (if applicable) are
compatible between the CPU and HMI.
If this does not reveal the source of the
problem, contact GE Service.
HMI Resumed Communication
with [CPUA/B]
Logged when HMI establishes
communications with a CPU
HMI Lost Communication with
[CPUA/B]
Logged when HMI can no longer
communicate with a CPU
HMI couldn't Establish
Communication with [CPUA/B]
Logged when HMI cannot establish a
communications session with a CPU
IP Address for CPUA Set To
[n.n.n.n] From [n.n.n.n]
Logged to record a change in the IP address
for the given CPU
IP Address for CPUB Set To
[n.n.n.n] From [n.n.n.n]
Logged to record a change in the IP address
for the given CPU
Table A-2 Sequence of events description and troubleshooting guide
Event
Description
Notes and Troubleshooting tips
