Introduction to FlexLogic
149
11
The operands available for this relay are listed alphabetically by operand type in Table 11-2.
Table 11-2 Entellisys FlexLogic operands
OPERAND TYPE
OPERAND SYNTAX
OPERAND DESCRIPTION
ELEMENT:
Breaker Control
BREAKER 1 OPENED
BREAKER 1 CLOSED
BREAKER 1 LOCKED OUT
BREAKER 1 CLOSED SPRING CHRGD
BREAKER 1 PRIMARY CONNECTED
BREAKER 1 PRIMARY DISCONNECTED
BREAKER 1 SECONDARY CONNECTED
Breaker 1 open
Breaker 1 closed
Breaker 1 locked out
Breaker 1 closing spring charged
Breaker 1 primary connected
Breaker 1 primary disconnected
Breaker 1 secondary connected
BREAKER 2…30
Same set of operands as shown for
BREAKER 1
ELEMENT:
Bus Differential
BD ZONE 1 TRIP DPO
BD ZONE 1 ALARM DPO
BD ZONE 1 TRIP PKP
BD ZONE 1 ALARM PKP
BD ZONE 1 TRIP OP
BD ZONE 1 ALARM OP
BD ZONE 1 TRIP BACKUP OP
Bus Differential Zone 1 trip function not in
pickup
Bus Differential Zone 1 alarm function not in
pickup
Bus Differential Zone 1 trip function in
pickup
Bus Differential Zone 1 alarm function in
pickup
Bus Differential Zone 1 trip function has
tripped breakers
Bus Differential Zone 1 alarm activated
Bus Differential Zone 1 trip backup function
has tripped backup breakers
BD ZONE 2…4
Same set of operands as shown for BD
ZONE 1
ELEMENT:
Ground Fault
GROUND FAULT 1 PKP
GROUND FAULT 1 OP
GROUND FAULT 1 DPO
Ground Fault 1 in pickup
Ground Fault 1 tripped breaker or activated
alarm
Ground Fault 1 not in pickup
GROUND FAULT 2…30
Same set of operands as shown for
GROUND FAULT 1
ELEMENT:
High Current
HIGH CURRENT 1 PKP
HIGH CURRENT 1 OP
HIGH CURRENT 1 DPO
High Current 1 in pickup
High Current 1 activated alarm
High Current 1 not in pickup
HIGH CURRENT 2…30
Same set of operands as shown for HIGH
CURRENT 1
ELEMENT:
High Resistance
Ground Fault
HRGF 1 PKP
HRGF 1 OP
HRGF 1 DPO
HRGF 1 in pickup
HRGF 1 activated alarm
HRGF 1 not in pickup
HRGF 2…30
Same set of operands as shown for HRGF 1
