Alarms and events description and system troubleshooting guide
227
A
Caution Messngr Not Receiving
From CPUB
Messenger reports that it is not receiving
data from CPU B
Check Ethernet connection between
Entellisys Messenger and switch, and the
connection between the switch and the
CPU B. Verify that CPU B is powered on and
operating.
System OK Receiving Broadcast
From CPUA
Messenger reports that it is receiving data
from CPU A
System OK Receiving Broadcast
From CPUB
Messenger reports that it is receiving data
from CPU B
Test Mode Initiated From Test
Kit
Messenger reports that test mode has been
initiated with the test kit
Test Mode Ended From Test Kit
Messenger reports that test mode has ended
Protection Suspended GF From
Test Kit
Messenger reports that ground fault
functionality is to be suspended
Protection Resumed GF From
Test Kit
Messenger reports that ground fault
functionality can resume
Attention Compartment ID
Button Missing
Messenger reports that it has detected that
the compartment ID button is missing
See DEH-235 Entellisys Low Voltage
Switchgear EntelliGuard Messenger iButton
Replacement Guide.
Note Messngr Error 5
Compartment ID Button contains valid
configuration data, but EEPROM copy is bad
See DEH-235 Entellisys Low Voltage
Switchgear EntelliGuard Messenger iButton
Replacement Guide.
Caution Check Compartment ID
Button Connection
Messenger reports that the compartment ID
button connection needs to be checked
See DEH-235 Entellisys Low Voltage
Switchgear EntelliGuard Messenger iButton
Replacement Guide.
Attention Messngr Error 1
Replace ASAP
Messengr reports that its application flash
memory has a CRC error and should be
replaced
Contact GE Post Sales Service (see
).
Attention Messngr Error 2
Replace ASAP
Messengr reports that its boot flash memory
has a CRC error and should be replaced
Contact GE Post Sales Service (see
).
Attention Messngr Error 3
Replace ASAP
Messenger reports that it has an analog IOC
error and should be replaced
Contact GE Post Sales Service (see
).
Attention Messngr Error 4
Replace ASAP
Messenger reports that it is not calibrated
and should be replaced
Contact GE Post Sales Service (see
).
CPU Status
Power On
CPU has powered on
Discrete IO Test Mode Initiated
Test mode for discrete I/O has been initiated
Discrete IO Test Mode Ended
Test mode for discrete I/O has ended
Table A-2 Sequence of events description and troubleshooting guide
Event
Description
Notes and Troubleshooting tips
