Introduction to FlexLogic 155
11
Logic Gate NOT Logic Not Operates on the previous
parameter.
OR (2)
↓
OR (16)
2 input OR gate
↓
16 input OR gate
Operates on the 2 previous
parameters.
↓
Operates on the 16
previous parameters.
AND (2)
↓
AND (16)
2 input AND gate
↓
16 input AND gate
Operates on the 2 previous
parameters.
↓
Operates on the 16
previous parameters.
NOR (2)
↓
NOR (16)
2 input NOR gate
↓
16 input NOR gate
Operates on the 2 previous
parameters.
↓
Operates on the 16
previous parameters.
NAND (2)
↓
NAND (16)
2 input NAND gate
↓
16 input NAND gate
Operates on the 2 previous
parameters.
↓
Operates on the 16
previous parameters.
XOR (2) 2 input Exclusive OR gate Operates on the 2 previous
parameters.
LATCH (S, R) Latch (Set, Reset) - reset-dominant The parameter preceding
LATCH (S, R) is the Reset
input. The parameter
preceding the Reset input is
the Set input.
Timer TIMER 1
↓
TIMER 64
Timer set with FlexLogic Timer 1 setting.
↓
Timer set with FlexLogic Timer 64
settings.
The timer is started by the
preceding parameter. The
output of the timer is TIMER
#.
Assign Virtual
Output = Virtual Output 1
↓
= Virtual Output
128
Assigns previous FlexLogic parameter to
Virtual Output 1.
↓
Assigns previous FlexLogic parameter to
Virtual Output 128.
The virtual output is set by
the preceding parameter.
Table 11-3 FlexLogic operators
Type Syntax Descriptions Notes
