Alarms and events description and system troubleshooting guide
225
A
Invalid Setting ST From CPUB
Change Rejected
Messenger has received an invalid short time
enable or disable setting from CPU B and has
rejected the value
This event is recorded by CPU A based on
status information sent to the Messenger by
CPU B. The Sequence of Events for CPU B
should have an “Invalid Setting ST Change
Rejected” or “Invalid Setting ST Pickup
Change Rejected” event. See the description
of those events for details.
Invalid Setting GF From CPUA
Change Rejected
Messenger has received an invalid ground
fault enable or disable setting from CPU A
and has rejected the value
This event is recorded by CPU B based on
status information sent to the Messenger by
CPU A. The Sequence of Events for CPU A
should have an “Invalid Setting GF Change
Rejected” or “Invalid Setting GF Pickup
Change Rejected” event. See the description
of those events for details.
Invalid Setting GF From CPUB
Change Rejected
Messenger has received an invalid ground
fault enable or disable setting from CPU B
and has rejected the value
This event is recorded by CPU A based on
status information sent to the Messenger by
CPU B. The Sequence of Events for CPU B
should have an “Invalid Setting GF Change
Rejected” or “Invalid Setting GF Pickup
Change Rejected” event. See the description
of those events for details.
Note Messngr Ignored Invalid
Command CPUA
Messenger has received an invalid command
from CPU A and will ignore it
Contact GE Post Sales Service (see
).
Note Messngr Ignored Invalid
Command CPUB
Messenger has received an invalid command
from CPU B and will ignore it
Contact GE Post Sales Service (see
).
Note Messngr Arbitrated
Command From CPUA
Messenger has received conflicting
commands from CPU A
Examine event logs from both CPUs to
determine if CPUs sent conflicting
commands at approximately the same time.
Note Messngr Arbitrated
Command From CPUB
Messenger has received conflicting
commands from CPU B
Examine event logs from both CPUs to
determine if CPUs sent conflicting
commands at approximately the same time.
Note Messngr Reports CPUA
Command Timed Out
Command sent to Messenger from CPU A has
timed out
• Verify that breaker is in the Test or
Connect position.
• If Open command timed out, check shunt
trip fuse.
• If Close command timed out, verify that
breaker is an electric breaker. If it is, verify
that closing spring is charged, also check
the fuse for the charging motor.
• Contact GE Post Sales Service (see
Note Messngr Reports CPUB
Command Timed Out
Command sent to Messenger from CPU B has
timed out
Same as CPU A above.
CPUA Synch Clock OK
Messenger reports that CPU A is using the
CPU Synch Clock (event recorded by CPU B)
Table A-2 Sequence of events description and troubleshooting guide
Event
Description
Notes and Troubleshooting tips
