Alarms and events 222
A
Synch Check 1…6 Dead Source
Operate Dead source criteria for synch check relay
1…6 have been met
Synch Check 1…6 Dead Source
Drop Out Dead source criteria for synch check relay
1…6 have been met
Synch Check 1…6 V1 Above
Minimum Voltage source 1 for synch check relay 1…6 is
above the live source threshold
Synch Check 1…6 V1 Below
Maximum Voltage source 1 for synch check relay 1…6 is
below the dead source threshold
Synch Check 1…6 V2 Above
Minimum Voltage source 2 for synch check relay 1…6 is
above the live source threshold
Synch Check 1…6 V2 Below
Maximum Voltage source 2 for synch check relay 1…6 is
below the dead source threshold
Overcurrent (including GF)
Pickup ST Overcurrent Short time overcurrent function has entered
pickup
Dropout ST Overcurrent Short time overcurrent function has dropped
out of pickup
Breaker Trip ST Overcurrent Breaker tripped due to short time overcurrent
condition
Pickup LT Overcurrent Long time overcurrent function has entered
pickup
Dropout LT Overcurrent Long time overcurrent function has dropped
out of pickup
Breaker Trip LT Overcurrent Breaker tripped due to long time overcurrent
condition
Pickup Ground Fault Ground fault function has entered pickup
Dropout Ground Fault Ground fault function has dropped out of
pickup
Breaker Trip Ground Fault Breaker tripped due to ground fault condition
Alarm Ground Fault Ground fault alarm has operated
Invalid Setting IOC Change
Rejected Attempt to enable or disable IOC has been
rejected The setting entered for IOC enable was
inconsistent with the protection options
configured at the Compartment ID. Verify
that the protection options are correct.
Table A-2 Sequence of events description and troubleshooting guide
Event Description Notes and Troubleshooting tips
