AASTRA SIP-DECT (Release 3.0)- OM System Manual - Installation, Administration and Maintenance EN - Manual (Page 177)

SIP–DECT OM System Manual Release 3.0 9 Configuration und Administration Aspects
Aastra depl-1624/1.0 Page: 177 (241)
TFTP Server Address Only mandatory for
RFP (L) 32/34 /
RFP (L) 42 WLAN
because of the
NETBOOT process;
Optional for
RFP (L) 35/36/37 IP /
RFP (L) 42 WLAN SW
update IP address of the TFTP server, set to
0.0.0.0 is not used
TFTP File Name Only mandatory for
RFP (L) 32/34 /
RFP (L) 42 WLAN
because of the
NETBOOT process;
Optional for
RFP (L) 35/36/37 IP /
RFP (L) 42 WLAN SW
update The boot file be read from the TFTP
server.
TFTP server list Only used by the
RFP (L) 32/34 /
RFP (L) 42 WLAN,
optional List of additional TFTP servers to load
the boot file
Preferred TFTP server Only used by the
RFP (L) 32/34 /
RFP (L) 42 WLAN,
optional Try to load the boot file from ‘TFTP
Server Address’ as first.
OMM IP Address mandatory IP address of the OpenMobility
Manager
Router addresses optional IP address of Default gateway
DNS Addresses optional IP address of DNS server
DNS Domain optional Domain name of the network
Broadcast Address optional The broadcast address for that network
2nd OMM IP Address optional IP address of the standby OMM
Country optional Defines the country in which the OMM
resides to handle country specific call
progress tones.
NTP Server Address optional IP address of an NTP Server
NTP Server Name optional Name of an NTP Server
VLAN ID optional VLAN identifier
Use VLAN and DHCP optional The parameter defines whether only
the local VLAN configuration settings
should be used when booting or not.
Syslog IP Address optional Destination IP address for the syslog
Syslog Port optional Destination port for the syslog
