SIP–DECT OM System Manual Release 3.0
9 Configuration und Administration Aspects
Aastra
depl-1624/1.0
Page: 171 (241)
LED1 (INFO)
LED2 (OMM /
SYSTEM)
LED3 (DECT) LED4 (WLAN)
RFP
general
1s
1s
OMM connect phase
1,85s
0,15s
OMM connection
failure (idle loop)
cont.
Up&Running (OMM
connected)
1,85s
0,15s
Up&Running + OMM
warning
1,85s
0,15s
Up&Running + OMM
failure
RFP DECT
cont.
DECT not configured
on this RFP
1,85s 0,15s
DECT inactive (not
synced yet)
cont
DECT 'on air'
1,85s 0,15s
DECT + call active
1,85s 0,15s
DECT + call active
+busy bit
RFP WLAN
cont.
WLAN not configured
on this RFP
1,85s 0,15s WLAN inactive yet
cont.
WLAN 'on air'
1,85s 0,15s
WLAN + assoc.
clients
cont.
WLAN failure (e.g. 10
Mbit uplink)
License
cont.
cont.
Branding mismatch
(RFP not functional)
Reboot
request
cont.
cont.
cont.
cont.
RFP will reboot
RFP (L) 32/34 IP, RFP 32/34 NA, RFP (L) 42 WLAN
LED1 (INFO)
LED2 (OMM /
SYSTEM)
LED3 (DECT) LED4 (WLAN)
Now, the kernel / application is running: LED1 will never be RED
Kernel
cont.
kernel boot phase
(inflator, …)
RFPM
1s
1s
DHCP phase
1,9s
0,1s
DHCP failure (idle
loop)
