SIP–DECT OM System Manual Release 3.0 9 Configuration und Administration Aspects
Aastra depl-1624/1.0 Page: 166 (241)
File Parameter named “Bootfile Name” with value of the
path (optional) and name of the application image. For
example “iprfp3G.dnld “ (current RFPs) or “iprfp2G.tftp”
(older RFPs). no (current
RFPs)
yes (older
RFPs)
code 1 Subnet mask yes
code 3 Default Gateway yes
code 6 Domain Name Server no
code 15 Domain Name no
code 42 IP address of a NTP server no
code 43 Vendor Specific Options yes
code 66 URL specifies the protocol, server and path to access
the RFP configuration files (see 9.8). no
public option 224 Parameter named magic_str must be set to value
"OpenMobility" or "OpenMobilitySIP-DECT". yes
Vendor specific options
The Vendor Specific Options consist of:
Vendor Specific
Option Meaning Length Mandatory
option 10 ommip1: Used to select the IP-RFP who
should reside the Open Mobility Manager
(OMM). 4 yes
option 14 syslogip: IP address of a Syslog Daemon 4 no
option 15 syslogport: Port of a Syslog Daemon 2 no
option 17 Country: Used to select the country in which
the OMM resides. This enables country
specific tones (busy tone, dial tone, …). 2 no
option 18 ntpservname: Name of a NTP Server x no
option 19 ommip2: Used to select a secondary IP-RFP
who should reside the standby Open Mobility
Manager (OMM). This option must be given if
the OMM Standby feature should be used
(see chapter 9.13). 4 no
option 24 rsturl: Restore URL
URL for an automatic OMM Database import
(see chapter 7.4.6.2 and chapter 8.5.5.1) x no
Example
An example of the minimal contents for the Option 43 parameter value would be:
0a 04 C0 A8 00 01 where “C0 A8 00 01” represents “192.168.0.1” for the OMM IP.
The option 43 contains a string of codes in hex the format is “option number” “length”
“value” in this example
0a = option 10 (ommip1)
04 = following value is 4 blocks long
C0 A8 00 01 = 192.168.0.1
