SIP–DECT OM System Manual Release 3.0 9 Configuration und Administration Aspects
Aastra depl-1624/1.0 Page: 176 (241)
On systems with multiple Ethernet adapters select the interface to use for the configuration of
the RFPs. To configure an RFP, at least the MAC address and all mandatory options (see
table below) have to be set. The MAC address must be entered in a format such as xx-xx-xx-
xx-xx-xx.
If the RFP has already an IP address, enter this address in the IP address field. In this case
you can reach the RFP from outside the local LAN segment. This setting is optional.
To set additional parameters, press the Add parameter button and choose the desired
parameter.
Please note: Select the yes checkbox for the RFP to Use local configuration otherwise
DHCP will be used.
Press the Send configuration button to transmit the parameters to an RFP.
Boot parameters (comply with DCHP options)
Parameter Type Meaning
Use local configuration mandatory The parameter defines whether the
local configuration settings should be
used when booting or not.
IP Address mandatory IP address of the RFP
Net mask mandatory Subnet mask of the IP network
