Chapter 18 VPN Screens
P-2602HWLNI User’s Guide
296
When there is outbound traffic but no inbound traffic, the SA times out automatically after two
minutes. A tunnel with no outbound or inbound traffic is "idle" and does not timeout until the
SA lifetime period expires. See
on keep alive to have the ZyXEL
Device renegotiate an IPSec SA when the SA lifetime expires, even if there is no traffic.
Figure 165 VPN: SA Monitor
The following table describes the fields in this screen.
Table 112 VPN: SA Monitor
LABEL
DESCRIPTION
No
This is the security association index number.
Name
This field displays the identification name for this VPN policy.
Encapsulation
This field displays Tunnel or Transport mode.
IPSec Algorithm
This field displays the security protocol, encryption algorithm, and authentication
algorithm used in each VPN tunnel.
Disconnect
Select one of the security associations, and then click Disconnect to stop that
security association.
Refresh
Click Refresh to display the current active VPN connection(s).
