Chapter 11 Voice

P-2602HWLNI User’s Guide

187

11.9 Advanced Analog Phone Setup Screen

Use this screen to edit advanced settings for each phone port. To access this screen, click
Advanced Setup in VoIP > Phone > Analog Phone.

SIP1 ~ SIP10

You must configure a SIP account in the VoIP > SIP screen before you can

receive VoIP phone calls. Select which SIP accounts you want to receive phone

calls from on this phone port. If you select more than one source for incoming

calls, there is no way to distinguish between them when you receive phone calls.

PSTN Line

Select this if you want to receive phone calls from the PSTN line (that do not use

the Internet) on this phone port. If you select more than one source for incoming

calls, there is no way to distinguish between them when you receive phone calls.

ISDN Line

Select this if you want to receive phone calls from the ISDN line (that do not use

the Internet) on this phone port. If you select more than one source for incoming

calls, there is no way to distinguish between them when you receive phone calls.

MSN

Select the MSNs you want the phone(s) connected to this phone port to receive.

When there is an incoming call with the corresponding MSN, the phones

connected to this port ring. Leave these fields blank if you do not use an MSN

service.
If you select more than one source for incoming calls, there is no way to

distinguish between them when you receive phone calls.

Note: The number in the MSN field refers to the MSN mapping

entries you configure in the VoIP > Fixed Line Numbers
screen. Configure these entries first.

Note: If you use an MSN service but do NOT configure MSNs in

this screen, when you select ISDN Line the phone(s)
attached to this port can receive calls that use any MSN.

Apply

Click this to save your changes and to apply them to the ZyXEL Device.

Cancel

Click this to set every field in this screen to its last-saved value.

Advanced Setup

Click this to edit the advanced settings for this phone port. The Advanced Analog

Phone Setup screen appears.

Table 64 Phone > Analog Phone

LABEL

DESCRIPTION
