Toshiba T2N - Manual (Page 41)

2.Specification
26 PROSEC T2N
Connectors on the Module : FCN-365P040/AU (made by Fujitsu)
Cable side connectors : Soldering type (standard attached)
Connector : FCN-361J040-AU (made by Fujitsu)
Connector cover : FCN-360C040-E (made by Fujitsu)
CN2
(A)(B)
CN1
(B)(A)
NC
NC
LC1
NC
NC
HC1
PS
FL
EL
DL
CL
BL
AL
9L
8L
LC0
7L
6L
5L
4L
3L
2L
1L
0L
FH
EH
DH
CH
BH
AH
9H
8H
HC0
7H
6H
5H
4H
3H
2H
1H
0H
PS
0H
1H
2H
3H
4H
5H
6H
7H
HC0
8H
9H
AH
BH
CH
DH
EH
FH
HC1
NC
NC
0L
1L
2L
3L
4L
5L
6L
7L
LC0
8L
9L
AL
BL
CL
DL
EL
FL
LC1
NC
NC
: Power Supply
24Vdc
CN2
A B
CN1
B A
1
20
20
1
CN1-L=XWn
CN1-H=XWn+1
CN2-L=XWn+2
CN2-H=XWn+3
1 1
2 2
3 3
4 4
5 5
6 6
7 7
8 8
9 9
10 10
11 11
12 12
13 13
14 14
15 15
16 16
17 17
18 18
19 19
20 20
L H
PS
PS
PS
PS
PS
PS
PS
20 20
19 19
18 18
17 17
16 16
15 15
14 14
13 13
12 12
11 11
10 10
9 9
8 8
7 7
6 6
5 5
4 4
3 3
2 2
1 1
H L
Terminal Connections
Derating Condition
21.6Vdc or less
24Vdc
26.4Vdc
32 (100
%
)
26 (80
%
)
20 (60 % )
Ambient temperature
Number of input ON points (per 1 conncctor)
0 10 20 30 40 50 60
