3.User Data
User's manual 173
*) Refer to the TOSLINE-F10 manual for details.
.
The corresponding bit comes ON when the LW register is
not updated normally.
.
The lowest adress of LW register corresponds to bit 0 in
the SW register, and in the order.
.
Biti assignment in the register is the same as SW078 and
SW079.
Special
Register
Name Function
SW080 TOSLINE-F10 CH2 command
SW081 TOSLINE-F10 CH2 status
SW082 TOSLINE-F10 CH3 command
SW083 TOSLINE-F10 CH3 status
SW084 TOSLINE-F10 CH4 command
SW085 TOSLINE-F10 CH4 status
SW086 TOSLINE-F10 CH5 command
SW087 TOSLINE-F10 CH5 status
SW088 TOSLINE-F10 CH6 command
SW089 TOSLINE-F10 CH6 status
SW090 TOSLINE-F10 CH7 command
SW091 TOSLINE-F10 CH7 status
SW092 TOSLINE-F10 CH8 command
SW093 TOSLINE-F10 CH8 status
Special
Register
Name Function
SW094
TOSLINE-F10
scan error map
LW000~LW015
SW095 LW016~LW031
SW096 LW032~LW047
SW097 LW048~LW063
SW098 LW064~LW079
SW099 LW080~LW095
SW100 LW096~LW111
SW101 LW112~LW127
SW102 LW128~LW143
SW103 LW144~LW159
SW104 LW160~LW175
SW105 LW176~LW191
SW106 LW192~LW207
SW107 LW208~LW223
SW108 LW224~LW239
SW109 LW240~LW255
