5. Programming Language
236
PROSEC T2N
(A) DPX (n) (B)
→
(C)
(A) TBM (n) (B) → (C)
(A) BTM (n) (B)
→
(C)
Ladder Diagram Instructions (Function Instructions)
Group
FUN
No.
Name Representation Summary
Number of
steps
required
Execution
time
required
( µ s)
Remarks
Rotate
91 Demultiplexer
Stores the contents of the register (A) in the (B)th
register of the table of size n headed by the register
(C).
7~9 154
92 Table -> bit transfer
Takes the (B)th bit from the head of the table of size
n words headed by the register (A) and stores it in
the device (C).
6~7 206
93 Bit -> table transfer
Takes the contents of the device (A) and stores them
in the (B)th bit of the table of size n headed by the
register (C).
6~7 189
