1.System Configuration
4 PROSEC T2N
•
Basic Configuration
•
I/O module
•
Data transmission Module
BU228N DC input DI31 DeviceNet scanner DN211
Rack BU268 DI32 SN221
BU266 DI235
TOSLINE-S20
SN222A
Power Supply PS261 AC input IN51 TOSLINE-F10 MS211
Module PS31 IN61 RS211
PU215N Transistor output DO31 LK11
CPU Module DO32
TOSLINE-30
LK12
PU235N DO235
PU245N DO233P
CAR3 Triac output AC61
Expansion Cable CAR5 Relay output RO61
CAR7 RO62
CS2RF AI21 •
Programming Tool
Analog input AI31
AI22 T-PDS
(for MS-DOS) MM33I1
AI32
AO31
T-PDS
(for Windows) MW33E1
AO22 Analog output
AO32
Handy
Programmer HP911
Pulse input PI21
Positioning module MC11
Serial interface CF211
Minimum and Maximum configuration are shown on next page.
As mentioned in Section 1.5 ,the following racks are available.
Part Number Application Number of Module
Installation
Remarks
TBU228N*S Dedicated to the
Basic unit
8
TBU268**S For expansion unit 8
TBU266**S For expansion unit 6
