User's manual
243
5. Programming Language
(A) MAVE (n) (B) → (C)
(A) DFL (B) → (C)
(A) UL (B) → (C)
(A) LL (B)
→
(C)
(A) MAX (n) (B)
(A) MIN (n) (B)
(A) AVE (n) (B)
(A) FG (n) (B) → (C)
(A) DB (B) → (C)
(A)+1·(A) RT (B)
(A) INTG (B) → (C)
(A) RAMP (B) → (C)
Ladder Diagram Instructions (Function Instructions)
Group
FUN
No.
Name Representation Summary
Number of
steps
required
Execution
time
required
( µ s)
Remarks
Function
56 Moving average
Moves the data of (A) to the n-word data table
headed by (B) and calculates the average value and
stores it in (C).
5 237+18.4n
61 Digital Filter
Calculates the data of (A) by the value of (B)
according to the filtering function and stores it in (C).
4 109
160 Upper limit
Applies an upper limit to the contents of (A) using the
value of (B), and stores the results in (C).
4~6 88
161 Lower limit
Applies a lower limit to the contents of (A), using the
value of (B), and stores the results in (C).
4~6 88
162 Maximum value
Searches the n-word data table headed by (A) for the
maximum value, stores the maximum value in (B),
and stores the pointer with the maximum value in
(B)+1.
4 150+18n
163 Minimum value
Searches the n-word data table headed by (A) for the
minimum value, stores the minimum value in (A), and
stores the pointer with the minimum value in (B)+1.
4 150+18n
164 Average value
Calculates the average value for the n-word data
table headed by (A), and stores it in (B).
4 138+17n
165 Function generator
Using the function defined by the 2x n parameters
headed by (B), finds the function value which takes
the contents of (A) as its argument, and stores it in
(C).
5~6 140
166 Dead band
Finds the value which gives the dead band indicated
by (B) for the contents of (A), and stores it in (C).
4~6 91
167 Square root
Finds the square root of the double-length data (A)+1
and (A), and stores it in (B).
3~5 102
168 Integral
Calculates the integral for the value of (A) from the
integral constant for (B)+1 and (B), and stores the
result in (C)+1•(C).
4~5 154
169 Ramp function
Generates the ramp function for the value of (A) the
parameters starting with (B), and stores it in (C).
4~5 246
