3. User Data
178
PROSEC T2N
Register
▼
Bit positions
Processable numerical ranges and expression formats are shown
in the following Table.
The numerical value when two complementary expressions are
added together is a value in which the lower 16 bits are all 0.
Example)
In calculation, the 2’s complements of a numerical value can be
found by the operation of inverting each bit of that numerical
value and adding 1.
Example)
(3)
BCD
BCD is the abbreviation of Binary Coded Decimal. BCD
expresses 1 digit (0 - 9) of a decimal number by 4 bits of a binary
number. Therefore, 1 register can express the numerical value of
a 4-digit decimal number.
10
3
10
2
10
1
10
0
0111 1111 1111 1111
(Binary) = 32767
(bit inversion)
1000 0000 0000 0001
(Binary)
(add 1)
0000 0000 0000 0000
(Binary) = – 32767
0111 1111 1111 1111
(Binary) = 322767
1000 0000 0000 0001
(Binary) = 322767
1
0000 0000 0000 0000
Numerical Value
(Decimal)
Binary Expression
Hexadecimal
Expression
32767
0111 1111 1111 1111
7FFF
32766
0111 1111 1111 1110
7FFE
∫
∫
∫
1
0000 0000 0000 0001
0001
1
0000 0000 0000 0000
0001
– 1
1111 1111 1111 1111
FFFF
∫
∫
∫
– 32767
1000 0000 0000 0001
8001
– 32768
1000 0000 0000 0000
8000
(MSB)
(LSB)
F
E
D
C
B
A
9
8
7
6
5
4
3
2
1
0
