3. User Data
174 PROSEC T2N
*) Refer to the TOSLINE-S20LP manual for details.
Special
Device
Name Function
S1100
TOSLINE-S20LP
station status
Test mode ON when test mode
S1101
Reserved (for future use) S1102
S1103
S1104 Master/slave ON when master station
S1105 Scan inhibit ON when scan transmission inhibit
S1106 Termination ON when the terminated station runs
S1107 Repeat status ON when repeat operation is executing
S1108 Loop2 transmission inhibit ON when Loop2 transmission inhibit
S1109 Loop2 receive inhibit ON when Loop2 receive inhibit
S110A Loop1 transmission inhibit ON when Loop1 transmission inhibit
S110B Loop1 receive inhibit ON when Loop1 receive inhibit
S110C Online ON when online mode
S110D Standby ON when standby mode
S110E Offline ON when offline mode
S110F Down ON when down mode
S1110
Reserved (for future use)
S1111
S1112
S1113
S1114
S1115
S1116
S1117
S1118
S1119
S111A
S111B
S111C
S111D
S111E
S111F
