5.RAS Functions
User’s manual 131
(3) Register value validity check function
This function checks that the register value is within the specified
numerical value range. There can be up to a maximum of 4 registers, a
minimum and maximum value is registered for each. Also, it is possible to
select the register value to be taken as an integer (signed) or as a positive
integer (unsigned).
The check is carried out immediately before starting a scan, the results are
stored in the special relay S0143-S0146 (within the range: 0, outside the
range: 1).
The register and the numerical value range are registered in programmer
system diagnosis mode.
XW034 unsigned 0 400 200
XW035 signed -1500 1500 2000
D0011 unsigned H0200 H9000 H1234
W0100 signed -300 600 -1000
comparison
result
registered
register
type minimum maximum present register
value
register 1 (XW034) .... S0143 = 0
register 2 (XW035) .... S0144 = 1
register 3 (D0011) ..... S0145 = 0
register 4 (W0100) .... S0146 = 1
