User's manual
233
5. Programming Language
(A) TSHR (m) → (B)
(A) TSHL (m) → (B)
D SR Q
S (n)
E (A)
D DSR Q
S (n)
E
L
(A)
SFT (A)
Ladder Diagram Instructions (Function Instructions)
Group
FUN
No.
Name Representation Summary
Number of
steps
required
Execution
time
required
(
µ
s)
Remarks
Shift
72 m bit file n bits shift right
When (B) is a register:
Takes the m-word table headed by (B), and shifts it
to the right (low address direction) by the number of
words indicated by (A).
When (B) is a device:
Takes the m-bit file headed by (B), and shifts it to the
right (LSB direction) by the number of bits indicated
by (A). The carry flag changes according to the
result.
4~5 ∗
73 m bit file n bits shift left
When (B) is a register:
Takes the m-word table headed by (B), and shifts it
to the left (high address direction) by the number of
words indicated by (A).
When (B) is a device:
Takes the m-bit file headed by (B), and shifts it to the
left (MSB direction) by the number of bits indicated
by (A). The carry flag changes according to the
result.
4~5 ∗
74 Shift register
If the enable input (E) is ON, then when the shift
input (S) comes ON, the instruction takes the
contents of the n devices headed by the device (A)
and shifts them 1 bit to the left. The carry flag
changes according to the result.
3 116
75 Bidirectional shift register
If the enable input (E) is ON, then when the shift
input (S) comes ON, the instruction takes the
contents of the n devices headed by the device (A)
and shifts them 1 bit to the left or to the right (the
shift direction depends on the state of the direction
input (L)). The carry flag changes according to the
result.
3 120
76 Device shift
Takes the contents of the device ((A)-1) which
immediatety precedes the device (A), stores them in
(A), and sets (A)-1 to 0
2 94
