3.User Data
User's manual 151
The following Table shows the types of registers and devices and their
address ranges. Their functions and methods of use are described in
Section 3.2.
In the T2N, 1 word is treated as equal to 16 bits, and the number of
registers is counted in word units.
NOTE
Function Type Type Code Address Range Quantity
Expression
Example
Input register XW
000~127 Total 128 words
XW001
Output register YW YW034
Direct input
register
IW IW001
Direct output
register
OW OW034
Input device X
0000~127F Total 2048 points
X001A
Output device Y Y0348
Direct input device I I0012
Direct output
device
O O0340
Auxiliary register RW 000~255 256 words RW100
Auxiliary device R 0000~255F 4096 points R1001
Special register SW 000~255 256 words SW014
Special device S 0000~255F 4096 points S0140
Timer register T 000~511 512 words T030
Timer device T. 000~511 512 points T.030
Counter register C 000~511 512 words C199
Counter device C. 000~511 512 points C.199
Data register D 0000~8191 8192 words D4055
Link register W 0000~2047 2048 words W0200
Link device Z 0000~999F 16000 points Z2001
Link relay register LW 0000~255 256 words LW123
Link relay L 0000~255F 4096 points L123F
File register F 0000~1023 1024 words F0500
Index register
I None 1 word I
J None 1 word J
K None 1 word K
Expanded
File register
-
accessing
by XFER instraction
24576 words -
