1.System Configuration
10 PROSEC T2N
(3) RUN/Stand-by Switch
Setting
Position
Mode after
power up
Remarks
SW.3
Function Operation
Mode
Switch
HALT HALT OFF Automatic
RUN RUN RUN Automatic RUN start occurs.
HALT ON Stand-by
RUN
HALT
Starts up in HALT mode. Ready
to start operation by RUN com-
mand from the programmer or by
shifting the operation mode
switch.(
→
HALT
→
RUN)
(4)(5)Selection Switch of optional Communication function
Setting Position Operation
SW.4 SW.5
Function
OFF OFF Computer Link The T2N can communicate with a master
computer using T-series computer link
protocol.
ON OFF Data Link The T2N executes data link with other T2N.
OFF ON Free ASCII The T2N can communicate with external
devices using ASCII code.
ON ON Reserved No operation.
(6)Programmer Port Parity
Setting
Position Function Remarks
SW.6
OFF Odd Parity 8 bit Data, 9600bps, Data length is 11bit.
ON No Parity 8 bit Data, 9600bps, Data length is 10bit.
The T2N can connect to Modem by using this switch.
Control signals (CTS,DTR,etc) should be set to No Use at the modem side.
Response of the T2N can be delayed on the programmer port using SW38
(Programmer port response delay mode register).
The RUN/Stand-by switch is set to RUN at the factory.
The Programmer Port Parity switch is set to Odd Parity at the factory.
1. These switches are set to computer link function at the factory.
2. For details of the operation mode, see Section 1.4.
NOTE
NOTE
NOTE
