Video Port Control Registers
Video Port
2-22
SPRU629
Table 2–8. Video Port Interrupt Enable Register (VPIE) Field Descriptions (Continued)
Bit
Description
Value
symval
†
field
†
20
VINTB1
Channel B field 1 vertical interrupt enable bit.
DISABLE
0
Interrupt is disabled.
ENABLE
1
Interrupt is enabled.
19
SERRB
Channel B synchronization error interrupt enable bit.
DISABLE
0
Interrupt is disabled.
ENABLE
1
Interrupt is enabled.
18
CCMPB
Capture complete on channel B interrupt enable bit.
DISABLE
0
Interrupt is disabled.
ENABLE
1
Interrupt is enabled.
17
COVRB
Capture overrun on channel B interrupt enable bit.
DISABLE
0
Interrupt is disabled.
ENABLE
1
Interrupt is enabled.
16
GPIO
Video port general purpose I/O interrupt enable bit.
DISABLE
0
Interrupt is disabled.
ENABLE
1
Interrupt is enabled.
15
Reserved
–
0
Reserved. The reserved bit location is always read as 0. A value
written to this field has no effect.
14
DCNA
Display complete not acknowledged bit.
DISABLE
0
Interrupt is disabled.
ENABLE
1
Interrupt is enabled.
13
DCMP
Display complete interrupt enable bit.
DISABLE
0
Interrupt is disabled.
ENABLE
1
Interrupt is enabled.
12
DUND
Display underrun interrupt enable bit.
DISABLE
0
Interrupt is disabled.
ENABLE
1
Interrupt is enabled.
11
TICK
System time clock tick interrupt enable bit.
DISABLE
0
Interrupt is disabled.
ENABLE
1
Interrupt is enabled.
† For CSL implementation, use the notation VP_VPIE_field_symval
