Video Display Registers
Video Display Port
4-58
SPRU629
Table 4–7. Video Display Control Register (VDCTL) Field Descriptions (Continued)
Bit
Description
Value
symval
†
field
†
Bit
Raw Data Mode
BT.656 and Y/C Mode
Value
symval
†
field
†
13
RGBX
RGB extract enable bit.
DISABLE
0
Not used.
ENABLE
1
Not used.
Perform
¾
FIFO unpacking.
12
RSYNC
Second, synchronized raw data channel enable bit.
DISABLE
0
Not used.
Second, synchronized raw data
channel is disabled.
ENABLE
1
Not used.
Second, synchronized raw data
channel is enabled.
11
DVEN
Default value enable bit.
BLANKING
0
Blanking value is output during
non-sourced active pixels.
Not used.
DV
1
Default value is output during
non-sourced active pixels.
Not used.
10
RESMPL
Chroma resampling enable bit.
DISABLE
0
Chroma resampling is disabled.
Not used.
ENABLE
1
Chroma is horizontally
resampled from 4:2:0
interspersed to 4:2:2 co-sited
before output.
Not used.
9
Reserved
–
0
Reserved. The reserved bit location is always read as 0. A value
written to this field has no effect.
8
SCALE
Scaling select bit.
NONE
0
No scaling
Not used.
X2
1
2
×
scaling
Not used.
7
CON
‡
Continuous display enable bit.
DISABLE
0
Continuous display is disabled.
ENABLE
1
Continuous display is enabled.
† For CSL implementation, use the notation VP_VDCTL_field_symval
‡ For complete encoding of these bits, see Table 4–4.
