Video Capture Registers
3-51 Video Capture Port SPRU629
Table 3–14. Video Capture Channel x Status Register (VCxSTAT)
Field Descriptions
Description
Bit field † symval † Value BT.656 or Y/C Mode Raw Data Mode TSI Mode
31 FSYNC Current frame sync bit.
CLEARD 0 VCOUNT = VINT1 or
VINT2, as selected
by the FSCL2 bit
in VCxVINT. Not used. Not used.
SET 1 VCOUNT = 1
in field 1. Not used. Not used.
30 FRMC Frame (data) captured bit. Write 1 to clear the bit, a write of 0
has no effect.
NONE 0 Complete frame has
not been captured. Complete data
block has not
been captured. Entire data packet
has not been
captured.
CAPTURED
CLEAR
1 Complete frame has
been captured. Complete data
block has been
captured. Entire data packet
has been
captured.
29 F2C Field 2 captured bit. Write 1 to clear the bit, a write of 0 has no
effect.
NONE 0 Field 2 has not been
captured. Not used. Not used.
CAPTURED
CLEAR
1 Field 2 has been
captured. Not used. Not used.
28 F1C Field 1 captured bit. Write 1 to clear the bit, a write of 0 has no
effect.
NONE 0 Field 1 has not been
captured. Not used. Not used.
CAPTURED
CLEAR
1 Field 1 has been
captured. Not used. Not used.
† For CSL implementation, use the notation VP_VCxSTAT_field_symval
