Video Capture Registers
3-49 Video Capture Port SPRU629
3.13 Video Capture Registers
The registers for controlling the video capture mode of operation are listed in
Table 3–13. See the device-specific datasheet for the memory address of
these registers.
Table 3–13. Video Capture Control Registers
Acronym Register Name Section
VCASTAT Video Capture Channel A Status Register 3.13.1
VCACTL Video Capture Channel A Control Register 3.13.2
VCASTRT1 Video Capture Channel A Field 1 Start Register 3.13.3
VCASTOP1 Video Capture Channel A Field 1 Stop Register 3.13.4
VCASTRT2 Video Capture Channel A Field 2 Start Register 3.13.5
VCASTOP2 Video Capture Channel A Field 2 Stop Register 3.13.6
VCAVINT Video Capture Channel A Vertical Interrupt Register 3.13.7
VCATHRLD Video Capture Channel A Threshold Register 3.13.8
VCAEVTCT Video Capture Channel A Event Count Register 3.13.9
VCBSTAT Video Capture Channel B Status Register 3.13.1
VCBCTL Video Capture Channel B Control Register 3.13.10
VCBSTRT1 Video Capture Channel B Field 1 Start Register 3.13.3
VCBSTOP1 Video Capture Channel B Field 1 Stop Register 3.13.4
VCBSTRT2 Video Capture Channel B Field 2 Start Register 3.13.5
VCBSTOP2 Video Capture Channel B Field 2 Stop Register 3.13.6
VCBVINT Video Capture Channel B Vertical Interrupt Register 3.13.7
VCBTHRLD Video Capture Channel B Threshold Register 3.13.8
VCBEVTCT Video Capture Channel B Event Count Register 3.13.9
TSICTL TSI Capture Control Register 3.13.11
TSICLKINITL TSI Clock Initialization LSB Register 3.13.12
TSICLKINITM TSI Clock Initialization MSB Register 3.13.13
TSISTCLKL TSI System Time Clock LSB Register 3.13.14
TSISTCLKM TSI System Time Clock MSB Register 3.13.15
