Video Port Pin Mapping
Overview 1-16 SPRU629
1.4.2 VDOUT Data Bus Usage for Display Modes
The alignment and usage of data on the VDOUT bus depends on the display
mode as shown in Table 1–4.
Table 1–4. VDOUT Data Bus Usage for Display Modes
Display Mode
BT.656 Y/C Dual Sync Raw Data Raw Data
Data Bus 10-Bit 8-Bit 10-Bit 8-Bit 8-Bit 10-Bit 16-Bit 20-Bit
VDOUT19 A (C) A (C) (B) (B) A A
VDOUT18 A (C) A (C) (B) (B) A A
VDOUT17 A (C) A (C) (B) (B) A A
VDOUT16 A (C) A (C) (B) (B) A A
VDOUT15 A (C) A (C) (B) (B) A A
VDOUT14 A (C) A (C) (B) (B) A A
VDOUT13 A (C) A (C) (B) (B) A A
VDOUT12 A (C) A (C) (B) (B) A A
VDOUT11 A (C) (B) A
VDOUT10 A (C) (B) A
VDOUT9 A A A (Y) A (Y) A A A A
VDOUT8 A A A (Y) A (Y) A A A A
VDOUT7 A A A (Y) A (Y) A A A A
VDOUT6 A A A (Y) A (Y) A A A A
VDOUT5 A A A (Y) A (Y) A A A A
VDOUT4 A A A (Y) A (Y) A A A A
VDOUT3 A A A (Y) A (Y) A A A A
VDOUT2 A A A (Y) A (Y) A A A A
VDOUT1 A A (Y) A A
VDOUT0 A A (Y) A A
Legend: A – Channel A display; A(C) Channel A chroma; A(Y) Channel A luma; B – Optional locked channel B display
