GPIO Registers
General Purpose I/O Operation
5-16
SPRU629
Table 5–8. Video Port Pin Data Set Register (PDSET) Field Descriptions
Bit
field
†
symval
†
Value
Description
31–23
Reserved
–
0
Reserved. The reserved bit location is always read as 0. A
value written to this field has no effect.
22
PDSET22
Allows PDOUT22 bit to be set to a logic high without affect-
ing other I/O pins controlled by the same port.
NONE
0
No effect.
VCTL3HI
1
Sets PDOUT22 (VCTL3) bit to 1.
21
PDSET21
Allows PDOUT21 bit to be set to a logic high without affect-
ing other I/O pins controlled by the same port.
NONE
0
No effect.
VCTL2HI
1
Sets PDOUT21 (VCTL2) bit to 1.
20
PDSET20
Allows PDOUT20 bit to be set to a logic high without affect-
ing other I/O pins controlled by the same port.
NONE
0
No effect.
VCTL1HI
1
Sets PDOUT20 (VCTL1) bit to 1.
19–0
PDSET[19–0]
Allows PDOUT[19–0] bit to be set to a logic high without
affecting other I/O pins controlled by the same port.
NONE
0
No effect.
VDATAnHI
1
Sets PDOUT[n] (VDATA[n]) bit to 1.
† For CSL implementation, use the notation VP_PDSET_PDSETn_symval
