Video Display Registers
Video Display Port
4-84
SPRU629
4.12.22
Video Display Display Event Register (VDDISPEVT)
The video display display event register (VDDISPEVT) is programmed with
the number of DMA events to be generated for display field 1 and field 2. The
VDDISPEVET is shown in Figure 4–60 and described in Table 4–27.
Figure 4–60. Video Display Display Event Register (VDDISPEVT)
31
28
27
16
Reserved
DISPEVT2
R-0
R/W-0
15
12
11
0
Reserved
DISPEVT1
R-0
R/W-0
Legend: R = Read only; R/W = Read/Write; -n = value after reset
Table 4–27. Video Display Display Event Register (VDDISPEVT) Field Descriptions
Description
Bit
field
†
symval
†
Value
BT.656 and Y/C Mode
Raw Data Mode
31–28
Reserved
–
0
Reserved. The reserved bit location is always read as 0. A
value written to this field has no effect.
27–16
DISPEVT2
OF(value)
0–FFFh
Specifies the number of DMA
event sets (YEVT, CbEVT,
CrEVT) to be generated for
field 2 output.
Specifies the number of DMA
events (YEVT) to be
generated for field 2 output.
15–12
Reserved
–
0
Reserved. The reserved bit location is always read as 0. A
value written to this field has no effect.
11–0
DISPEVT1
OF(value)
0–FFFh
Specifies the number of DMA
event sets (YEVT, CbEVT,
CrEVT) to be generated for
field 1 output.
Specifies the number of DMA
events (YEVT) to be
generated for field 1 output.
† For CSL implementation, use the notation VP_VDDISPEVT_DISPEVTn_symval
