GPIO Registers
5-21 General Purpose I/O Operation SPRU629
5.1.10 Video Port Pin Interrupt Polarity Register (PIPOL)
The video port pin interrupt polarity register (PIPOL) is shown in Figure 5–10
and described in Table 5–11. The PIPOL determines the GPIO pin signal
polarity that generates an interrupt.
Figure 5–10. Video Port Pin Interrupt Polarity Register (PIPOL)
31 24
Reserved
R-0
23 22 21 20 19 18 17 16
Reserved PIPOL22 PIPOL21 PIPOL20 PIPOL19 PIPOL18 PIPOL17 PIPOL16
R-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0
15 14 13 12 11 10 9 8
PIPOL15 PIPOL14 PIPOL13 PIPOL12 PIPOL11 PIPOL10 PIPOL9 PIPOL8
R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0
7 6 5 4 3 2 1 0
PIPOL7 PIPOL6 PIPOL5 PIPOL4 PIPOL3 PIPOL2 PIPOL1 PIPOL0
R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0 R/W-0
Legend: R = Read only; R/W = Read/Write; -n = value after reset
