78
Using the sequencer to create patterns (Pattern mode)
Selecting the types of music data
for viewing (View Filter)
You can specify the types of music data that will be displayed. Since
you can specify that only certain events will be displayed, this lets
you rapidly find the data that you are looking for.
1.
In the Microscope screen, press [PARAM].
2.
Use PAGE/CURSOR [
]/[
] to select the type of music
data, and use VALUE [-]/[+] to turn “ON” the display of music
data that you wish to view.
VALUE
Note:
OFF, ON
Poly After (Polyphonic Aftertouch):
OFF, ON
Ctrl Change (Control Change):
OFF, ON
Prog Change (Program Change):
OFF, ON
Ch After (Channel Aftertouch):
OFF, ON
Pitch Bend:
OFF, ON
SysEx (System Exclusive):
OFF, ON
3.
Press [EXIT] to return to the Microscope screen.
Microscope Utility
Microscope Utility provides various functions. For details on each
menu, refer to the corresponding reference page.
1:
INS (Insert Event) (p. 78)
2:
DEL (Delete Event) (p. 78)
3:
MOVE (Move Event) (p. 78)
4:
COPY (Copy Event) (p. 78)
5:
PASTE (Paste Event) (p. 78)
If you want to display a clock location at which no event is
recorded, move the cursor to the clock and press [NUMERIC] so
it is lit. Use [0]–[9] to specify the desired value, then press
[ENTER].
Inserting music data (INS)
1.
In the Microscope screen, display the location (measure–
beat–clock) at which you want to insert an event.
2.
Press [UTILITY].
3.
Press [1] to select “1.INS.”
4.
Use VALUE [-]/[+] to select the type of music data that will be
inserted.
fig.r06-48_40
You can insert the following events.
Note
PAft:
Polyphonic Aftertouch
CtrlChg:
Control Change
ProgChg:
Program Change
Ch After:
Channel Aftertouch
PitchBend:
Pitch Bend
Tune:
Tune Request
SysEx (Default):
System Exclusive
SysEx (GM-ON):
System Exclusive (GM-ON)
SysEx (GM2-ON):
System Exclusive (GM2-ON)
SysEx (GM-OFF):
System Exclusive (GM-OFF)
5.
Press [ENTER] to execute.
Deleting music data (DEL)
1.
In the Microscope screen, display the event that you want to
delete.
2.
Press [UTILITY].
3.
Press [2] to select “2.DEL.”
The event will be deleted.
The event that you deleted can be pasted in later if desired.
“Pasting music data (PASTE)”
(p. 78)
Moving music data (MOVE)
1.
In the Microscope screen, display the event that you want to
move.
2.
Press [UTILITY].
3.
Press [3] to select “3.MOVE.”
4.
Input the location (measure–beat–clock) to which you want
to move the event.
fig.r06-49_40
Use PAGE/CURSOR [
]/[
] to select measure–beat–clock,
and use VALUE [-]/[+] to input the value. Or, press [NUMERIC] so
it is lit, use [0]–[9] to specify the desired value, then press [ENTER].
5.
Press [ENTER] to execute.
Copying music data (COPY)
If you execute
copy
, that event will be temporarily saved, allowing
you to
paste
it to the desired location.
1.
In the Microscope screen, display the event that you want to
copy.
2.
Press [UTILITY].
3.
Press [4] to execute “4.COPY.”
Pasting music data (PASTE)
If you execute
copy
, that event will be temporarily saved, allowing
you to
paste
it to the desired location.
1.
In the Microscope screen, display the desired location you
want to paste the copied event.
2.
Press [UTILITY].
3.
Press [5] to execute “5.PASTE.”
