147
Performing with a computer
Performing with a
computer
Windows Me/98 users
1.
With the RS-70 disconnected, start up Windows.
Disconnect all USB cables except for a USB keyboard and USB mouse (if used).
2.
Exit all currently running software (applications).
Also close any open windows. If you are using virus checking or similar software, be
sure to exit it as well.
3.
Prepare the CD-ROM.
Insert the CD-ROM into the CD-ROM drive of your computer.
4.
Open the “Run...” dialog box.
Click the Windows Start button.
From the menu that appears, select “Run...”
fig.Win-22.e
5.
In the dialog box that appears, input the
following into the
“Open” field, and click [OK] .
E:\Win98\RS-70\SETUPINF.EXE
* The drive name “E:” may be different for your
system. Specify the drive name of your CD-ROM drive.
fig.Win-23.e
6.
The SetupInf dialog box will appear.
You are now ready to install the driver.
7.
Connect the RS-70.
1. With the RS-70’s power switch turned
off, connect it to the AC adaptor.
2. Plug the AC adaptor into an AC power
outlet.
3. Use the USB cable to connect the RS-70 to your computer.
8.
Set the RS-70’s power switch to the ON position.
fig.Win-24.e
9.
If you are using Windows 98, an Insert
Disk dialog box will appear.
Click [OK] .
In this manual, the location
of folders and files is given
in terms of the file path,
using \ as the delimiter.
For example,
Win98\SETUPINF.EXE
indicates the
SETUPINF.EXE
file found
in the Win98 folder.
This unit is equipped with
a protection circuit. A brief
interval (a few seconds)
after power up is required
before the unit will operate
normally.
If you are using Windows
98 and the Insert Disk
dialog box dose not appear,
please read The “Insert
Disk” dialog box does not
appear (p. 161).
