153
Performing with a computer
Performing with a
computer
OMS settings
1.
Connect the RS-70.
1. With the RS-70’s power switch turned off, connect it to the AC adaptor.
2. Plug the AC adaptor into an AC power outlet.
3. Use the USB cable to connect the RS-70 to your computer.
fig.Mac-03.e
* If using a computer that is not equipped with a USB connector, refer to p. 155.
2.
Set the RS-70’s power switch to the ON position.
fig.Mac-04
3.
Double-click the “OMS Setup” icon.
fig.Mac-05.e
4.
If the “Apple Talk” dialog box appears,
click [Turn It Off] .
Then, in the dialog box that appears next,
click
[OK] .
fig.Mac-06.e
5.
The “Create a New Studio Setup” dialog
box appears.
Click [OK] .
fig.Mac-07.e
6.
The “OMS Driver Search” dialog box
appears.
Click [Search] .
RS-70
USB cable
Computer
To prevent malfunction
and/or damage to speakers
or other devices, always
turn down the volume, and
turn off the power on all
devices before making any
connections.
This unit is equipped with
a protection circuit. A brief
interval (a few seconds)
after power up is required
before the unit will operate
normally.
If you are using the RS-70
with a sequencer, do not
disconnect the USB cable
connected to the RS-70
while a song is playing
back.
If the “Create a New
Studio Setup”
dialog box
does not appear, click [New
Studio Setup]
in the [File]
menu.
