A-2

Item Express5800/140He

Keyboard

MINI DIN 6-pin connector (1 port)

Mouse

MINI DIN 6-pin connector (1 port)

USB

4-pin (3 ports; front: 1 (USB1.1), rear: 2 (USB2.0))

Serial

D-sub 9-pin (2 ports, rear), RJ-45 (1 port, front (exclusively used with
either port on the rear panel))

Parallel

D-sub 25-pin (1 port)

Network

RJ-45 (2 ports and 1 management port)

Display

MINI D-sub 15-pin (1 port)

External
interface

SCSI –

Cabinet design

Middle-Tower

External dimensions

310 (width) × 456 (height) × 805 (depth) mm

Weight

75 kg (Max.)

Power supply

100 to 127 Vac ±10%, 200 to 240 Vac ±10%, 50/60 Hz ±1Hz

Power consumption

1800 VA

Temperature

10 to 35°C

Environmental
requirements

Humidity

20 to 80% RH (no condensation)

Others

NEC EXPRESSBUILDER supported, NEC ESMPRO provided in the
standard configuration
