background image

Psion Teklogix WORKABOUT PRO With Windows Mobile 2003 SE User Manual

311

Chapter 10: Specifications

E1022 Linear 1D Imager Scanner

Figure 10.2 SE 923 Scanner

10.3.3 E1022 Linear 1D Imager Scanner

Humidity:

5% to 95% noncondensing

Power:
Input Voltage:
Input Current:
Standby Current:

3.0-5.5 VDC ± 10%
65 mA typical
8 µA max

Shock

2000 G

Output Power (peak)

0.94mW

Parameter

E1022

Optics

645 nm visible red top LED
Bright and sharp scanning line

Sensor

CCD linear image sensor

Scan Rate

270 scans/s auto-adaptive

Scan Angle

48°

Skew and Pitch

+/-35°

Min. x Dimension

Down to 0.05 mm (2mil)

Depth of Field

0 to 49.2 cm (19.4'')

Bar Code Width

up to 18 cm (7'') on 0.3

Print Contrast

Down to 20%

Symbologies

UPC (E&A), EAN, Code 39, Code 128, UCC EAN
128, ISBN, Interleaved, Matrix, Industrial and Stan-
dard 2 of 5, Codabar, Code 93, MSI, Plessey,
Telepen. Others including ISBT on request.

Programmable
Parameters

Laser On Time, Aim Duration, Power Mode, Trigger
Mode, Bi-directional Redundancy, Symbology
types/lengths, Data formatting, Serial Parameters,
Beeper Tone, Scan Angle

Interfaces

Decoded: RS232 TTL

Ambient Light

Works in any lighting
conditions, from 0 to 100 000 lux

Operating Temperature

0 to 50°C (32 to 122°F)

Parameter

SE 923
