Chapter 9: Peripheral Devices & Accessories
AC Wall Adaptor And Tether Cable
296
Psion Teklogix WORKABOUT PRO With Windows Mobile 2003 SE User Manual
Figure 9.17 Bottom Of WORKABOUT PRO
Connecting a wall adaptor (WA3220) and tether cable (CA1050) to your
WORKABOUT PRO will supply AC power to your unit. The tether cable is
equipped with a tether port so that you can attach a peripheral device to the
hand-held while providing power. A power lead must be ordered separately.
•
Insert the tether connector into the tether port on your hand-held. Tighten
the screws to secure the cable in place.
•
Insert the DC power plug into the DC IN socket on the tether cable, connect
the AC power lead to the Universal AC Power Supply.
•
Plug the pronged end of the lead into an AC outlet.
Tether
Port
Audio
Jack
Low Insertion
Force Port
(LIF)
