4-26 SANRAD V-Switch CLI User Manual
Checking IP Routes
After creating an IP routing path, you can ping any IP-connected device from
the V-Switch Eht1 to check that the routing is configured correctly. Use the CLI
command ping to ping an IP address from the V-Switch. Make sure that the
route is defined on the other side as well.
ping
You need one parameter to check an IP routing path from the V-Switch.
S WITCH P ARAMETER D EFINITION S TATUS E XAMPLE
-ip IP ADDRESS IP ADDRESS TO
PING
MANDATORY 172.17.200.69
ping –ip 172.17.200.69
Viewing IP Routes
After creating an IP routing path to an external network, you can view it and
any other configured IP routing path. Use the CLI command ip route show
to view a V-Switch’s routing table.
ip route show
Table 4-6: V-Switch IP Routing Paths
Dest IP
Address
Dest Mask Interface Gateway TOS
10.10.20.20 255.255.255.0 Eth2 30.30.20.20
10.12.40.40 255.255.255.0 Eth3 20.22.11.11
Removing an IP Route
You can remove unwanted IP routing paths from your V-Switch. Use the CLI
command ip route remove to remove an IP routing path. If you are
working in a V-Switch cluster, the IP route must be removed from both V-
Switch databases. For more information on V-Switch clusters, see
“
Introduction to V-Switch Clusters ”.
