Chapter 3: Installing the V-Switch 3000
3-7
The V-Switch 3000 supports up to four storage ports in any combinations in
pairs of the following:
Table 3-2:
Storage Port Connection Types
FC
C
ONNECTOR
L
ENGTH
F
IBRE
C
HANNEL
1
G
BIT
/2
G
BIT
NL_
PORT OR
N_
PORT OF EITHER
:
S
HORT
-
WAVE LASER FOR MULTIMODE
FIBER
U
P TO
550
M
L
ONG
-
WAVE LASER FOR SINGLE
-
MODE
FIBER
U
P TO
10
KM
C
OPPER
(1
G
BIT
) U
P TO
25
M
Your exact port
configuration will
depend on your V-
Switch 3000 order
specifications.
SCSI
U
LTRA
3
LVD
160MB/
SEC
68
PIN PORT
U
P TO
12
M
There are four storage ports LEDs, labeled FC/SCSI 1, 2, 3 &4, on the front right
of the V-Switch 3000 for up to four storage ports.
10
217
Storage Port LEDs
Figure 3-5. V-Switch 3000 Storage Port LEDs
Network Port Connections
The network ports, labeled Eth 1, 2 & 3, are located on the front right of the V-
Switch 3000. Use the 1Gb Ethernet ports to connect to the network or directly
to the host station.
Each network port has both a fiber optic and copper connector but only one
cable, either fiber optic or copper, can be connected to each port. To connect a
fiber-optic cable you need a Small Form Factor Package (SFP) optical
transceiver to couple to the fiber optic cable and insert into the network SFP
port. Please refer to Figure 3-6.
