Chapter 5 Installing Additional Memory
57
To install additional memory in the HP NetServer, refer to the following
procedure.
1. To gain access to the HP NetServer, perform one of the procedures listed
below.
NOTE It is not necessary to remove the system board from the
HP NetServer to install the additional DIMM memory.
◊ If the NetServer is mounted on the pedestal, perform Steps 1-8 in the
"Removing Covers – Pedestal (LC 2000)" in Chapter 3, "Opening and
Closing the HP NetServer," to gain access to the NetServer.
◊ If the NetServer is in the rack, perform steps 1-14 in the "Removing
Covers – Rack Mount (LC 2000r)" in Chapter 3, "Opening and Closing
the HP NetServer," to gain access to the NetServer.
2. Locate the DIMM slot for installation and spread the two retaining clips
outward to accept the DIMM. See Figure 5-2.
3. Remove the HP DIMM from its container, handling the module by its
edges.
If you must lay it down, place it on an anti-static mat.
Figure 5-2. Opening Retaining Clips
4. Align the notches on the DIMM with the keys on the DIMM slot, holding
the DIMM at a 90
°
angle to the system board. See Figures 5-2 and 5-3.
