Chapter 2 Controls, Ports, and Indicators
14
Rear Panel Indicators and Ports
The HP NetServer’s rear panel includes communication ports, the AC power
inlets, and the NetServer’s power supplies.
Figure 2-4 shows the rear of the HP NetServer.
Communication
Ports
AC Power
Inlets
Power
Supply #1
Redundant
Power
Supply #2
(Optional)
Knockout for
External
SCSI Connector
(Optional)
Figure 2-4. Rear Panel of the HP NetServer
CAUTION To prevent a power supply from overheating, ensure the other
power supply opening remains covered, if a second supply is
not used. If the second supply is used, keep the cover in case
you need to remove one supply for repair.
