Chapter 13 Alternative Rack Mounting
154
The slides click into position when locked. This locked position prevents
the slides from moving back into the rack, unless the release latches are
pressed as shown in Figure 13-9.
CAUTION The HP NetServer weighs 80 lbs. (36 kg). To avoid accidents,
use two people when placing the HP NetServer into the rack.
4. With the help of at least one other person, lift the NetServer by its four
handles.
5. Move the rear of the NetServer just beyond the extended slide members.
6. Position the NetServer’s channels on each side to insert the slide members
into the channels. See Figure 13-7.
7. Move the slide members into the NetServer’s channels until both slide
members are underneath all four of the NetServer's handles, including the
mounting tabs. See Figures 13-7 and 13-8.
Mounting
Tabs
Channels(2)
Figure 13-7. Mounting the Chassis on the Slides
