97
9 Connecting the Monitor, Keyboard,
Mouse, and UPS
Introduction
This chapter provides the instructions for connecting a monitor, keyboard, mouse
and Uninterruptible Power Supply (UPS) to the rear of the HP NetServer.
Connecting the Monitor, Keyboard, and Mouse
To connect the peripheral control devices and monitor to the HP NetServer
LC 2000/2000r, refer to the following procedure.
1. Connect the monitor, keyboard, and mouse to the HP NetServer
LC 2000/2000r using the connections provided on the rear of the chassis.
See Figure 9-1.
Keyboard Mouse
Video NIC
(Embedded) Serial Management
Figure 9-1. Connection Ports (rear of chassis)
