Chapter 2 Controls, Ports and Indicators
13
Non-Hot Swap Device Indicators
The indicators for non-Hot Swap devices, which provide operational status, are
also shown in Figure 2-3. The indicators shown in Figure 2-3 also apply to the
rack-mount model (LC 2000r). See Table 2-4 for Backup Tape drive LED Codes.
Table 2-4. Backup Tape Drive LED Codes
Left LED Right LED Definition
Off Off No Power
On Off Cartridge Loaded, but No activity
Flashing* Off Cartridge Loaded and Active
Pulsing** Off Loading/Unloading/Ejecting/Power-On
Off On Self Test Fail
Off Pulsing** No Cartridge, but Caution (cleaning required)
On Pulsing** Cartridge Loaded, but Caution (cleaning required)
Flashing* Pulsing** Cartridge Loaded, Drive Active, Caution (cleaning
required)
Pulsing** Pulsing** Cartridge Loading/Unloading, Caution (cleaning
required)
* Flashing at 4 Hz rate
** Pulsing at 2 Hz rate
NOTE For more information on the HP Tape Drive and its error
codes, refer to the documentation provided with the tape drive
or refer to Hewlett-Packard’s web site, at:
http://www.hp.com .
Refer to Chapter 4, "Installing Mass Storage Devices," for
installation information.
